4 Ton chiller systems

choose your configuration

DESCRIPTION

SA-SERIES

4 Ton

PACKAGED AIR
COOLED CHILLER

This 4 ton unit is set up with internal reservoir and pumps. One pump (chiller circulation pump) circulates the chiller's evaporator to keep the chiller's internal tank at the target set point temperature. The other pump (process supply pump) pulls out of the chiller’s internal reservoir, circulates to your downstream application, and returns back to the chiller's internal reservoir.

FOR MORE INFORMATION

DESCRIPTION

SA-SERIES

4 Ton

PACKAGED RACK-STYLE AIR COOLED CHILLER

This 4 ton unit is a packaged rack-style system with multiple independent refrigerant circuits for increased redundancy. This unit is also set up with internal reservoir and pumps. One pump (chiller circulation pump) circulates the chiller's evaporator to keep the chiller's internal tank at the target set point temperature. The other pump (process supply pump) pulls out of the chiller’s internal reservoir, circulates to your downstream application, and returns back to the chiller's internal reservoir.

FOR MORE INFORMATION

DESCRIPTION

SAP-SERIES

4 Ton

PORTABLE PACKAGED AIR
COOLED CHILLER

This 4 ton unit is equipped with casters (wheels) for simplified portability.
This 4 ton unit is set up with internal reservoir and pumps. One pump (chiller circulation pump) circulates the chiller's evaporator to keep the chiller's internal tank at the target set point temperature. The other pump (process supply pump) pulls out of the chiller’s internal reservoir, circulates to your downstream application, and returns back to the chiller's internal reservoir.

FOR MORE INFORMATION

DESCRIPTION

SAR-SERIES

4 Ton

SPLIT AIR COOLED CHILLER
WITH HEAT TRANSFER SKID

This 4 ton system is made up of 2 main components. The first component is an Air-Cooled Condenser Unit (ACCU), which is typically installed outdoors in order to deflect the heat to the outside atmosphere. The second component is the Heat Transfer Pump Tank Skid (HTPTS), which is typically installed indoors. The HTPTS contains evaporator(s), refrigerant liquid and suction line components, water/glycol reservoir, and pumps. One pump (chiller circulation pump) circulates the chiller's evaporator to keep the chiller system's reservoir tank at the target set point temperature. The other pump (process supply pump) pulls out of the chiller’s internal reservoir, circulates to your downstream application, and returns back to the chiller's internal reservoir.

FOR MORE INFORMATION

DESCRIPTION

SAE-SERIES

4 Ton

MODULAR AIR COOLED CHILLER

This unit is a 4 ton chiller system only. It does not include a tank or pumps, so a tank and pumps will need to be supplied by others to work in conjunction with this unit. If you would like a separate quote for a packaged unit with pumps and tank, let us know.

FOR MORE INFORMATION

DESCRIPTION

SAE-SERIES

4 Ton

MODULAR AIR COOLED CHILLER
WITH PUMP TANK SKID

This 4ton complete system is made up of a Modular Air-Cooled Chiller Unit and a Pump Tank System Skid.

FOR MORE INFORMATION

DESCRIPTION

RAR-SERIES

4 Ton

MULTI-SPLIT AIR COOLED CHILLER
SYSTEMS
WITH HEAT TRANSFER SKID

This 4 ton complete system is made up of Split Air-Cooled Condenser Units and a Heat Transfer Pump Tank Skid.

FOR MORE INFORMATION

DESCRIPTION

RAE-SERIES

4 Ton

MULTI-MODULAR
AIR COOLED CHILLER SYSTEMS WITH PUMP TANK SKID

This 4 ton complete system is made up of Modular Air Cooled Chiller Units and a Pump Tank System Skid.

FOR MORE INFORMATION

DESCRIPTION

SW-SERIES

4 Ton

PACKAGED WATER COOLED CHILLER

Evaporator Side: This 4ton unit's evaporator side is set up with internal reservoir and pumps. One pump (chiller circulation pump) circulates the chiller's evaporator to keep the chiller's internal tank at the target set point temperature. The other pump (process supply pump) pulls out of the chiller’s internal reservoir, circulates to your downstream application, and returns back to the chiller's internal reservoir.
Condenser Side: A cooling tower loop or other condenser water loop is required to circulate the water-cooled condenser side of this system. No pump or reservoir is provided for the condenser side circulation. Whaley can provide a separate cooling tower and/or pump/strainer/control station to circulate the condenser side of this chiller system if needed.

FOR MORE INFORMATION

DESCRIPTION

SWE-SERIES

4 Ton

MODULAR WATER COOLED CHILLER

Evaporator Side: An evaporator circulation loop is required to circulate the evaporator side of this 4 ton system. No pump or reservoir is provided for the evaporator side circulation. Whaley can provide a separate quote for a packaged water-cooled chiller with integral pumps/reservoir for the evaporator side circulation and process application circulation, if needed.
Condenser Side: A cooling tower loop or other condenser water loop is required to circulate the water-cooled condenser side of this 1.5 ton system. No pump or reservoir is provided for the condenser side circulation. Whaley can provide a separate cooling tower and/or pump/strainer/control station to circulate the condenser side of this chiller system if needed.

FOR MORE INFORMATION

PACKAGED AIR COOLED CHILLER

PACKAGED RACK STYLE AIR COOLED CHILLER

MODULAR WATER COOLED CHILLER

PACKAGED WATER COOLED CHILLER

PORTABLE PACKAGED AIR COOLED CHILLER

SPLIT AIR COOLED CHILLER WITH HEAT TRANSFER SKID

MULTI-SPLIT AIR COOLED CHILLER SYSTEMS WITH HEAT TRANSFER SKID

MODULAR AIR COOLED CHILLER WITH PUMP TANK SKID

MODULAR AIR COOLED CHILLER

MULTI-MODULAR AIR COOLED CHILLER SYSTEMS WITH PUMP TANK SKID

Configurations

Features

Contact

Options

Quote

10-Ton Cooling Towers

4 Ton Chiller Features

4 ton chiller systems – many models and configurations to choose from for your heat removal needs and customized with the right options.

Evaporator Upgrade Options - Insulated Coaxial Tube-in-tube, Plate and Frame, Stainless Steel

Pump Upgrade Options - Style, Material, Seal Type

Hand-Off-Auto Switches for Remote Start Capability

Variable Frequency Drive Packages

Low Ambient Packages

Back Up Pump Upgrade Options - Duplex, Swing, Loose

Whale-soft Tested and Certified

Refrigerant Safety Switches

Audible Alarm Packages

Temperature Control Packages

Remote Panel Options

NEMA-4 Rated Control Panels with Upgrade Options
